Hybrid inverter SMA Sunny Boy Smart Energy 3.6

The SMA Sunny Boy Smart Energy single-phase hybrid inverter is a two-in-one solution for the generation and flexible use of solar energy at home.

Sunny Boy Smart Energy is the ideal path to a comprehensive home energy transformation. Being both a photovoltaic and battery-powered inverter, it provides reliable and stable power supply. With built-in failsafe power supply and optional battery backup feature 1) it will continue to operate even in the event of a power failure.

Three MPP trackers allow different roof orientations to be taken into account in solar power plans. The hybrid inverter ensures very fast charging of connected batteries and allows you to make the most of days with only a few hours of sunshine.
Heat pumps, electric vehicle charging solutions and intelligent energy management can be flexibly integrated into the energy system at any time. This means greater independence from rising electricity prices and traditional energy sources. With Sunny Boy Smart Energy, users can count on the high quality standards inherent in a product made in Germany.

Maximum Energy Output
• Fast charging and discharging of connected batteries.
• Increased PV system size for higher energy output
• Integrated yield optimization with SMA ShadeFix.

Easy installation, quick commissioning
• Connection via standard cables
• SMA Easy Lock for easy opening and closing of the lid.
• Step-by-step commissioning via the SMA 360° app (depending on software version).

Unrivaled flexibility
• Three MPP trackers for flexible roof layout.
• Low starting voltage
• Built-in safe power supply.
• Additional backup function 1)

Improved storage options
• Compatible with SMA home battery.
• Compatible with high-voltage batteries from major manufacturers (depending on software version).

1) Available in later hardware version.

Technical data Sunny Boy Smart Energy 3.6

Photovoltaic DC
Max. Photovoltaic battery power: 7200 W.
Max. input voltage: 600 V
Min. input voltage: 60V
MPP voltage range: 60V to 480V.
Trigger input voltage: 66V
Max. useful input current A/B/C: 15 A
Max. Short circuit DC input A/B/C: up to 30A 6)
Number of independent MPP inputs/inputs per MPP: 3/1
Parallel connection of MPP inputs A and B is possible.

DC battery
Battery type: Li-ion batteries 1)
Voltage range: 90 V to 500 V.
Max. charging current/max. Discharge current: 30A/30A
Number of independent battery inputs: 1
Max. Charging power: 10000W
Max. discharge power: 3750 W

AC power
Rated power (at 230 V, 50 Hz): 3600 W
Max. total AC power (at 230 V, 50 Hz): 3600 VA
Rated AC voltage: 230V/240V
AC voltage range: 184V to 264V.
AC Frequency/Range: 50Hz/60Hz/44-66Hz
Nominal/Max. output current: 16A/16A
Power factor at rated power/adjustable bias power factor: 1/0.8 overexcited to 0.8 underexcited.

Efficiency
Max. efficiency / European efficiency: 97.5% / 96.8%

SPS (Standby AC) output in standalone mode
Rated power (at 230 V): 3680 W
Max. total AC power (at 230 V, 50 Hz): 3680 VA
Rated AC voltage: 230V/240V
AC Frequency: 50Hz/60Hz
Switching mode: Manual

Backup output 3) (backup AC) in stand-alone mode, single-phase
Rated power (at 230 V, 50 Hz): 7300 W
Max. total AC power (at 230 V, 50 Hz): 7300 VA
Day off power/apparent output power < 100 ms: 11,040 W/11,040 VA
Output power / Total output power < 30 s: 9200 W / 9200 VA
Rated AC voltage: 230V/240V
AC Frequency: 50Hz/60Hz
Switching mode / Time to switch to standby mode: automatic / TBD

Protective devices
Inlet side cut-off point: ●
Arc fault circuit breaker (AFCI): ●
Ground fault monitoring/network monitoring: ● / ●
DC reverse polarity protection / AC short circuit current capacity: ● / ●
All-pole residual current monitoring device: ●
Protection class: I
Overvoltage category: mains/battery/photovoltaic: IV/II/II
DC surge protector type II with monitoring (external, third party): ○

Total information
Dimensions (W/H/D): 500 x 586 x 236 mm.
Weight approx.: 17.5 kg.
Operating temperature range: -25°C to +60°C with derating.
Noise level, max.: TBD
Self-consumption (at night): TBD
Topology/cooling method: transformerless/natural convection.
Degree of protection (according to IEC 60529) / climate category (according to IEC
60721-3-4): IP65/4K26
Max. permissible relative humidity (non-condensing): 100%

Equipment
PV connection/BAT connection: lever clamp/plug clamp
Display via smartphone, tablet, laptop: ●
Communication protocols: Modbus (SMA, Sunspec), Speedwire/Webconnect, SMA battery interface, MODBUS RTU
Interfaces: WLAN / Ethernet / BAT-CAN / RS-485: ● / ● / ● / ●
Ethernet ports: 2
Number of digital outputs: SG-ready (multifunction relay, 30 V DC / 1 A4))
Shade control: SMA ShadeFix (built-in): ●
Warranty: 5/10/15/20 years: ● / ● 5) / ○ / ○
Planned certifications and approvals (more information available upon request): AS4777-2; C10/11; CEI0-21; EN50549-1; IEC 62109-1/IEC 62109-2; TED749; VDE-AR-N4105
Country of availability of SMA Smart Connected: BE, DE, ES, LU, NL, IT.
Type designation: SBSE3.6-50

● Standard Features ○ Optional  Information refers to nominal “TBD” conditions to be defined later. Status as of 06/2023.
1) See “List of Approved Batteries” on www.SMA-Solar.com.
2) 4600 W / 4600 VA according to VDE-AR-N 4105
3) Available in later hardware version.
4) Available in later firmware.
5) Device registration within 30 days via SMA product registration at
my.sma-service.com. SMA Limited Factory Warranty terms apply. More information can be found at SMA-solar.com.
6) the sum at all inputs should not exceed 60 A.

SMA ShadeFix – intelligent energy optimization
Established product features and integrated software solutions will ensure yield optimization throughout the life of the system. This is true even in the shadows. SMA ShadeFix is ​​a patented inverter software that optimizes energy output in almost any situation. SMA Smart Connected inverter monitoring provides added safety by detecting errors at an early stage and automatically reporting them to the installer.

SMA ArcFix – effective prevention of electric arcs
An Arc Fault Interrupter (AFCI) effectively detects possible electrical arcs in a PV system and the inverter stops supplying power before a fire can occur. SMA was one of the pioneers in introducing AFCI in the United States and has continually improved the solution over the past decade. In the future, we will equip all of our string inverters worldwide with our AFCI SMA ArcFix solution. In this way, we will consistently improve the already high safety standards of photovoltaic systems.

SMA Smart Connected – proactive communication in case of failures
SMA Smart Connected allows you to monitor your inverter for free through the SMA Sunny portal. If If the inverter fails, SMA will inform the system operator and installer in advance. This saves valuable working time and costs.

With SMA Smart Connected, the installer benefits from fast diagnostics using SMA. This allows the installer to quickly fix the problem and offer customers a number of additional and very attractive services.
