Inverter SMA SHP 75-10 (75kW)

Network three-phase inverter Sunny Tripower of the third generation. Winner of Inter Solar 2017, SMA engineers have developed an inverter that combines a unique design with an innovative installation method, significantly reducing installation time and providing all target groups with maximum return on investment. Possibility of integration into SMA FUEL SAVE SOLUTIONS systems. At the moment - the best solution for commercial stations at an attractive price.

Specifications

DC input (solar panels)
Max. power (at cos = 1) / Rated power 51000 W / 51000 W
Max. input voltage 1000 V
MPP Range / Nominal Input Voltage 150 - 1000 V / 500 - 800 V
Min. input voltage/start voltage 150V/188V
Max. operating current/per 1 MPPT tracker 120 A/20 A
Max. short circuit current per 1 MPPT/per string 30 A/30 A
Number of MPP trackers/number of strings per MPPT 6/2
AC output
Rated power (at 230 V, 50 Hz) 50000 W
Maximum power 50000 VA
Rated voltage 3/N/PE; 220V/380V
3/N/PE; 230V/400V
3/N/PE; 240V/415V
Voltage range 180 V - 280 V
Frequency/Range 50 Hz/44 Hz - 55 Hz
Rated frequency/voltage 50 Hz/380 V
Maximum output current/rated output current 72.5 A/72.5 A
Number of phases 3 3
THD 3%
Efficiency >98%
Dimensions (width x height x depth) 621 mm / 733 mm / 569 mm
Weight 82 kg
Degree of protection according to IEC 60529 IP65
Interface Ethernet, WLAN
